Automation and plant engineering

• Idle speed up to 5480 rpm
• Stall torque up to 1.5 Nm
• Rated torque 0.2 Nm
• Rated speed up to 4664 rpm

• Idle speed up to 5168 rpm
• Stall torque up to 1.1 Nm
• Rated torque 0.1 Nm
• Rated speed up to 4600 rpm

• Idle speed up to 1653 rpm
• Stall torque up to 2.9 Nm
• Rated torque  0.5 Nm
• Rated speed up to 1390 rpm

• Idle speed up to 4053 rpm
• Stall torque 2 Nm
• Rated torque up to 0.3 Nm
• Rated speed up to 3770 rpm

• Idle speed up to 4324 rpm
• Stall torque 2.5 Nm
• Rated torque 0.6 Nm
• Rated speed up to 3895 rpm

• Idle speed  up to 1390 rpm
• Stall torque up to 9 Nm
• Rated torque 1.9 Nm
• Rated speed up to 1185 rpm

• Idle speed  up to 2600 rpm
• Stall torque up to 7 Nm
• Rated torque 1.3 Nm
• Rated speed up to 2360 rpm

• With feather key groove
• 7 reduction ratios from 1:1 to 47:1

• Axis distance 15 mm

• With feather key groove
• 9 reduction ratios from 1:1 to 65:1

• Axis distance 20 mm

• With feather key groove
• 9 reduction ratios from 1:1 to 64:1

• Axis distance 30 mm

• With splined shaft connection
• 9 reduction ratios from 1:1 to 65:1

• Axis distance 20 mm

• Axis distance 20 mm
• Backlash < 0.5 mm
• Max. speed 100 mm/s

• Axis distance 20 mm
• Backlash < 0.5 mm
• Max. speed 100 mm/s

• With turntable
• 9 reduction ratios from 1:1 to 65:1

• Axis distance 20 mm
• With one drive pin or with trough-screw

• With turntable
• Backlash: < 0.05° (3‘) to MDrive = 0.1 Nm / < 0.5° (30‘) to MDrive = 1 Nm
• With one drive pin or with through going axis

2x solid shaft

• 10 sizes
• Backlash at drive shaft 3° ± 1°

• Ratio 1:1

1x solid shaft, 1x blind hollow shaft

• 4 sizes
• Backlash at drive shaft 3° ± 1°

• Ratio 1:1

3x shaft in synchronization/counter-rotation

• 10 sizes
• Ratio 1:1
• Backlash at drive shaft 3° ± 1°


1x blind hollow shaft and solid shaft in synchronization

• 4 sizes
• Ratio 1:1
• Backlash at drive shaft 3° ± 1°


1x solid shaft, 2x blind hollow shaft in counter rotation

• 4 sizes
• Ratio 1:1
• Backlash at drive shaft 3° ± 1°


• Max. load pull/push 800 N
• Ratio 1,44:1, 1,5:1
• Type of spindle Tr12x3

• Max. pressure 3000 N
• Movement speed 4 mm/s
• with throughgoing push-pull spindle

• Rated torque 40 Nm
• Idle running speed 1 U/min.
• Reduction total 3500:1

• Customer-specific
• Various manual switches
• Appropriate cables

• RPM up to 1.300
• Torque up to 10 Nm
• Peak torque up to 13 Nm

• No gearbox – no wear

• Rated speed 530 rpm
• Achievable max. speed up to 31 km/h

• No gearbox – no wear

• Rated speed 316 rpm
• Achievable max. speed up to 14 km/h

• No gearbox – no wear

• Rated speed 154 rpm
• Achievable max. speed up to 7 km/h

• Our ultra-compact gearless i-Wheel C 3213 direct drive with a fully integrated Synapticon Circulo 9 safety controller in use

• Gearless BLDC wheel hub drives
• Very smooth running
• Maintenance-free
