Mobility
Mobility
Bevel gear with spindle unit 3039
Max. Lifting force 800-1200 N
Type of spindle SG14x16, Tr14x3
Ratio 1:1
Bevel gear 3869 - 3872
Ratio 1:1
Drive torque 10 Nm
Housing die-cast zinc
Inline spindle drive 3120
Installation-space requirement 40 x 77 mm
Lifting force 800 N
Movement speed 43 mm/s
DC-Motor drive 3143
Rated torque 2,8 – 5 Nm
Idle running speed up to 230 rpm
One and double-threaded drive versions
Electric spindle drive 4640
Installation length = Stroke+109 mm
Lifting force 800 N
Movement speed 40 mm/s
Motor drive 4773
Rated torque 40 Nm
Idle running speed 1 U/min.
Reduction total 3500:1
Brushless DC motor 3207 – i-Rex-A-130-70
RPM up to 1.300
Torque up to 10 Nm
Peak torque up to 13 Nm
Hand control for controller Compact and motor cables
Customer-specific
Various manual switches
Appropriate cables
BLDC wheel hub motor i-Wheel 3213.00-1XXX
No gearbox – no wear
Rated speed 530 rpm
Achievable max. speed up to 27 km/h
BLDC wheel hub motor i-Wheel 3213.00-2XXX
No gearbox – no wear
Rated speed 316 rpm
Achievable max. speed up to 14 km/h
BLDC wheel hub motor i-Wheel 3213.00-3XXX
No gearbox – no wear
Rated speed 154 rpm
Achievable max. speed up to 7 km/h
