BLDC motors from Ketterer – Powerful, precise, and yet also small

BLDC motors (brushless DC motors) from Ketterer are powerful, brushless electric motors. They are available in variants as internal rotors and external rotors and combine high torques with minimal space requirements. If an encoder system is integrated, the motor is suitable as a servo drive. The number of windings and circuitry can be adapted to the customer’s application. In the external rotor motor version, the outer surface moves around the fixed axis. A BLDC motor from Ketterer is a powerful, precisely controllable drive that is used, among other areas, in electromobility as well as in automated guided vehicles (AGVs) and automated guided carts (AGCs).

Ketterer has developed the modular drive platform “Ket-Rob” for this purpose. “Ket-Rob” forms the basis for customer-specific automated guided vehicles (AGVs) or automated guided carts (AGCs) and can be quickly and flexibly adapted to individual requirements in practice. The platform consists of a slim frame made of aluminum profiles to which two drive wheels and four free-moving wheels are attached. The gearless BLDC wheel hub drives have a durable wheel covering made of Vulkollan or solid rubber. Ketterer’s “Ket-Rob” can save many development steps and resources when developing an innovative AGV or AGC.

Are you looking for a BLDC motor for your application or are you in the process of developing your own automated guided vehicle system? Ketterer’s strong development team would be happy to support you every step of the way.

Product brochure BLDC motors

Brochure wheel hub motors

BLDC motor: Torque motors t-Rex

  • Internal rotor
  • Small and compact designed for high torques
  • With hollow shaft of various diameters
  • All motors are available with application-specific number of windings and adapted wiring versions.
  • The performance data of the motors depend on the number of windings and the wiring version.
  • Customer applications can be realized.

BLDC motor: Torque motors i-Rex

  • Outrunner motor
  • With very high torques
  • Well suited for use as direct drive
  • All motors are available with application-specific number of windings and adapted wiring versions.
  • The performance data of the motors depend on the number of windings and the wiring version.
  • Customer applications can be realized.

The i-Wheel series 3213 in action

Ket-Rob - Drive platform for AGV/AGC

Ket-Rob - Drive platform for AGV/AGC

KuLi - electrical short stroke actuator

KuLi - electrical short stroke actuator

Brushless DC motor 3200 – t-Rex-I-44-89

Brushless DC motor 3200 – t-Rex-I-44-89

Brushless DC motor 3206 – t-Rex-I-65-86

Brushless DC motor 3206 – t-Rex-I-65-86

Brushless DC motor 3207 – i-Rex-A-130-70

Brushless DC motor 3207 – i-Rex-A-130-70

BLDC wheel hub motor i-Wheel 3213.00-1XXX

BLDC wheel hub motor i-Wheel 3213.00-1XXX

BLDC wheel hub motor i-Wheel 3213.00-2XXX

BLDC wheel hub motor i-Wheel 3213.00-2XXX

BLDC wheel hub motor i-Wheel 3213.00-3XXX

BLDC wheel hub motor i-Wheel 3213.00-3XXX
